Reuleaux DNA 200 Quick Guide

The Reuleaux DNA 200 consists of back cover, 510 spring connector, fire button, ventilation holes, OLED screen, up button, down button and charging port. How to use it?


1. Lock/ Unlock: Tap the fire button and the screen will display “Locked, Click 5X”. Press the fire button five times in quick succession to lock and unlock the device.

2. Profiles setting: Reuleaux allows you to save and select between eight groups of output settings. Each group of output settings is called a Profile. In 6. Reverse Polarity System for Batteries: If installed improperly, the plastic hoop will prevent the battery touching the opposite contact head. Power Locked mode, double click the up or down button to cycle between profiles. To select the displayed profile, press the fire button.

3. Stealth function: In locked mode, holding the fire and down buttons simultaneously will switch to stealth mode. In this mode the display is off. Switch back to normal display mode in the same way.

4. Power locked function: Holding down both the up and down buttons will place the device in Power Locked mode. Exit Power Locked mode in the same way.

5. Resistance locked function: In locked mode, hold both the fire and up buttons to enter Resistance Lock mode. To disable resistance lock, repeat the procedure.

6. Reverse Polarity System for Batteries: If installed improperly, the plastic hoop will prevent the battery touching the opposite contact head.

Note: In TC mode, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled down before attaching, the temperature may read and protect incorrectly until the new atomizer cools. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to confirm this change and a message will prompt “New Coil? UP YES/DOWN NO”. Press the up button to confirm that a new atomizer has been attached. Press the down button to confirm that the same atomizer has been reconnected.
