Beyond Vape User Manual

Function
1. Stealth Function: While the device is on, simultaneously hold the fire button and the down button. This will switch the screen display on and off.

2. Resistance Lock Function: While the device is on, simultaneously hold the fire button and the up button to enter Resistance Lock mode. To disable resistance lock, repeat the procedure.
(Note: Such operation should be carried out at room temperature.)

3. Adjustment Lock function: While the device is on, simultaneously press the up and down buttons. This will Lock and Unlock the adjustment button functions.

4. Micro USB Port Function: The USB port can be used for upgrading firmware, but it is recommended that the battery is removed to charge.

5. Switch the Display Mode: To rotate the screen display 180 degrees, press the up and down buttons simultaneously in shutdown(power off) state.


How to Power on/ off
Unscrew the bottom cover and put one 26650 cell into the battery body. Press the fire button 5 times in quick succession to turn the device on and off.

You can also use one 18650 cell with the help of battery sleeve, and then the maximum output power recommended is 75W.

How to Shift Modes
When the device is powered on, press the fire button 3 times in quick succession to enter the mode switching state. By pressing the up or down button to shift among TC-Ni, TC-Ti, TC-SS, TCR M1, TCR M2, TCR M3, VW and Bypass mode.

Note:
1. In TC modes, be careful to attach new atomizers that have cooled to room temperature. If a new atomizer has not cooled down before attaching, the temperature may read and protect incorrectly until the new atomizer cools.

2. When you connect a new atomizer or disconnect and reconnect your existing atomizer, the device will prompt you to confirm this change and a message will prompt “new coil up same down”. Press the up button to confirm that a new atomizer has been attached. Press the down button to confirm that the same atomizer has been reconnected.

3. When using non-TC coils or TC coils with a resistance higher than 1.5ohm in TC modes, the device will automatically switch to VW mode.
