User Manual For Eleaf iKuun i200 Kit

Notice for Use

Thank you for choosing Eleaf ikuun i200 kit Greece! Please read this manual carefully before use so as to use correctly. If you require additional information or have questions about the product or its use, please consult your local agents, or visit our website at www.istick.org.

How to use?


Power on/off: press the fire button 5 times in quick succession to turn on/off the device. Keep holding the fire button to take a puff when the device is powered on.

Stealth on/off: Press the fire button and “-” button simultaneously when the device is powered on to switch between Stealth On and Stealth Off mode. In Stealth On mode, you can vape with the OLED screen off and you can press the fire button once to see current setting.

Adjustment buttons lock/unlock: keep pressing “+” button and “-” button simultaneously for two seconds when the device is powered on, then the adjustment button will be locked and the screen will display “Key Lock”. In the same way, the adjustment button can be unlocked and the screen will display “Key Unlock”.

Switch display mode: keep pressing “+” button and “-” button simultaneously for two seconds when the device is powered off, the screen display will rotate 180 degrees. You can view the screen from two different angles through this operation.

Parameter setting: Parameters include V (current voltage), A (current amp), P (total vaping puffs) and S (total vaping seconds).
1. When in VW (Power) Mode, press the fire button 3 times, and then press “-” button once. When the current parameter is flashing, press “+” button to switch among V, A, P and S parameters.
2.When in TEMP/TCR mode, if current parameter that is displayed on the screen is W, press the fire button 3 times, and then press “-” button twice. When W is flashing, press the “-” button once again to A, and then press ”+” button once repeatedly to P, S and back to W.

Preheat function: When the device is powered on, simply keep holding the fire button and “+” button simultaneously to enter into the regulation interface. Then press “+” button once to enter into Preheat Setting Menu. Press the fire button to switch between preheat power and time. Press “+” or “-” button to adjust. Long press the fire button to confirm.

Power Bank Function: When the device is powered on, press the fire button and “+” button simultaneously, and then press “+” button twice to enter into the USB Charge interface and press “-” button to switch between On and Off. Choose On the activate reverse charge function. Press the fire button 3 times and then press “+” button to switch between different modes. Choose the USB Charge mode, connect with your electronic device via the USB cable to charge.

Switch vaping modes: press the fire button 3 times in quick succession to enter into the mode options. Then press “+” button to switch between VW/TEMP (Ni, Ti, SS316) / TCR (M1, M2, M3) modes. Press the fire button once to confirm. In TEMP / TCR mode, while it is flashing, press “-” button to enter into its subsidiary menu. Then press “+” button to choose among: Ni / Ti / SS316 (TEMP mode) or M1/ M2/ M3 (TCR mode). Press the fire button to confirm.

Adjust Temperature: in TEMP (Ni, Ti, SS)/ TCR (M1, M2, M3) mode, temperature can bu adjusted from 100-315℃ or 220-600℉ by pressing “+” or “-” button, “+” button to increase and “-” to decrease. Each press of the “+” or “-” button will increase or decrease the temperature setting by 5℃ or 10℉. Keep pressing “+”or “-” button without looseness can rapidly increase or decrease temperature setting.

If you have any question about the usage of Eleaf products, feel free to ask us at our Facebook eleaf vape store. We'll be glad to help you!
